H Series Low Profile Torque Wrench

H low profile torque wrenches designed for accessing limited areas and serves goog solutions with numbers of replaceable cassettes and adaptors. Drivers can be replaced easil and fast without using any tolls. Saves time by means of easy replacement of attachments. Light weight aluminum design allows easy operations even in robust conditions.

CONTACT US

Product characteristics

- The reaction pawl officially overcome the possibility of ratchet reversing opposite;enhance the effciency and precision of torque.
- 360°×360° degree swivel allow the wrench free to operation with no space limitation.

Operation manual

Click download

Specifications

Download parameter table

Product selection form

Dimension Drawing



Technical Data

model

Torque

(N.m)

Bolt size

(mm)

Weight

Kg

Sizes
L H1 H2 W1 W2 A
H27

262~2625

306~3068

19~46

50~60

0.9

193

193

125

136

97

108

32

32

51

51

10~15

10~11

H54

537~5372

603~6037

27~65

70~80

1.9

250

250

158

169

125

136

41

41

64

64

11~19

11.7~12

H120

1173~11737

1434~14349

50~80

85~105

3.4

310

310

189

214

157

182

52

52

78

78

15~15.2

16~22

H210

2121~21216

2312~23124

70~100

105~115

5.9

378

378

223

236

191

204

64

64

97

97

8~21

18~24

H430

4379~43792

4848~48481

80~117

120~175

16.1

405*

425*

291*

309*

242*

260*

83

83

93

93

25~31*

25~34*


Choice of Cassettes

H27
H54
H120
H210
H430
Type R A Max Torque Type
R A Max Torque
Type
R A Max Torque
Type
R A Max Torque
Type
R A Max Torque
H27-19 26 15 2625 H54-27 36 19 5372 H120-50 44 15 11737 H210-70 59 18 21216 H430-80 72 85 43792
H27-22 26 14 2625 H54-30 35 17 5372 H120-55 47 15 11737 H210-75 62 18 21216 H430-85 78 28 43792
H27-27 26 11 2625 H54-32 35 16 5372 H120-60 50 15 11737 H210-80 65 18 21216 H430-90 78 25 43792
H27-30 28 11 2625 H54-34 35 16 5372 H120-65 53 15 11737 H210-85 68 21 21216 H430-95 84 28 43792
H27-32 28 10 2625 H54-36 35 14 5372 H120-70 56 15 11737 H210-90 71 18 21216 H430-100 84 26 43792
H27-34 31 11 2328 H54-41 35 11 5372 H120-75 58 15 11737 H210-95 77 21 21216 H430-105 90 28 43792
H27-36 31 10 2625 H54-46 37 11 5858 H120-80 61 15 11737 H210-100 77 18 21216 H430-110 94 31 43792
H27-41 34 10 2625 H54-50 41 12 5372 H120-85 66 16 14349 H210-105 79 18 23124 H430-115 94 28 43792
H27-46 37 10 2625 H54-55 44 13 5372 H120-90 69 16 14349 H210-110 87 24 23124 H430-117 94 28 43792
H27-50 40 11 3068 H54-60 47 12 5372 H120-95 71 16 14349 H210-115 87 21 23124 H430-120 101 31 48481
H27-55 42 11 3068 H54-65 50 12 5372 H120-100 77 22 14349



H430-125 101 28 48481
H27-60 50 10 3068 H54-70 52 12 6037 H120-105 77 19 14349



H430-130 101 25 48481




H54-75 56 12 6037







H430-135 105 26 48481




H54-80 58 12 6037







H430-140 110 29 48481
















H430-145 110 26 48481
















H430-150 115 29 48481
















H430-155 115 26 48481
















H430-160 121 29 48481
















H430-165 121 26 48481
















H430-170 128 30 48481
















H430-175 128 27 48481

technical data

- 700 bar maximum working pressure;Repeat accuracy ±3%.
- 5 different model from 2625-48481N.m
- Fitted with 360°×360° uni-swivel quick release couplings
- Low profile design to accessing limited areas
- Drivers and adaptors can be repl
